Deye
Deye Inverter On-Grid 25kW 2MPPT | SUN-25K-G05
Product Code: Deye Inverter On-Grid 25kW 2MPPT | SUN-25K-G05
€689.00
+ VAT based on country
High-efficiency 25kW three-phase on-grid solar inverter with 2 MPPT trackers, 1100V PV input and up to 98.5% efficiency. Designed for commercial and large residential photovoltaic systems.
Key Features
- Nominal AC output power of 25 kW for three-phase grid-connected systems
- Three-phase grid connection designed for stable and reliable power delivery
- High conversion efficiency of up to 98.5% for maximum solar energy yield
- Low total harmonic distortion (THD) for compliant and stable grid interaction
- Wide output voltage and frequency compatibility with international grid standards
- Dual MPPT trackers allowing independent optimization of two PV strings
- Wide MPPT voltage range enabling flexible photovoltaic array design
- Maximum PV input voltage up to 1100 V DC for long string configurations
- High PV input capability suitable for modern high-power solar modules
- Advanced MPPT tracking algorithms for improved performance under varying sunlight conditions
- Designed for grid-tied photovoltaic power systems
- Stable power conversion for continuous solar energy export to the grid
- Support for export limitation and zero-export configurations when required
- Reliable synchronization with the utility grid for stable operation
- Suitable for commercial rooftops and distributed solar installations
- Integrated intelligent monitoring platform for system performance tracking
- Optional remote monitoring via WiFi, LAN, GPRS, Bluetooth, or 4G modules
- Communication interfaces supporting RS485 and RS232 protocols
- Real-time monitoring of PV production and inverter operating status
- Remote system configuration and maintenance support
- Compact wall-mounted inverter design for efficient installation
- Robust enclosure suitable for indoor and outdoor environments
- Integrated protection systems for installer and equipment safety
- Clearly labeled connections for fast and reliable installation
- Designed for professional solar installers and EPC projects
- Comprehensive protection including over-voltage, over-current, and short-circuit protection
- Integrated DC reverse polarity and insulation monitoring protection
- Anti-islanding protection for safe grid operation
- High reliability components designed for long service life
- Compliant with international grid and electrical safety standards
- Commercial solar PV installations
- Large residential photovoltaic systems
- Industrial self-consumption solar projects
- Distributed rooftop solar power systems
- Grid-connected photovoltaic energy systems
Technical Specifications
General
- Brand
- Deye
- Model
- Deye Inverter On-Grid 25kW 2MPPT | SUN-25K-G05
- SKU
- Deye Inverter On-Grid 25kW 2MPPT | SUN-25K-G05
- Power Output
- 25000 W
- Efficiency
- 98.5%
- Dimensions
- 362 × 527 × 220 mm
- Weight
- 20 kg
- Warranty
- 120 months
Technical
- Input Voltage
- 250–1100 V DC
- Output Voltage
- 220/380 V – 230/400 V AC (three-phase)
- Frequency
- 50/60 Hz
- MPPT Range
- 200–1000 V DC
- Max PV Power
- 32500 W
- Max PV Voltage
- 1100 V DC
- Max PV Current
- 26A + 26A
- Nominal Power
- 25000 W
- Peak Power
- 27500 W
- THD
- <3%
- Power Factor
- 0.8 leading – 0.8 lagging
- Operating Temperature
- -25°C to +60°C
- Protection Rating
- IP65
- Cooling
- Intelligent air cooling
- Noise Level
- ≤50 dB
- Certifications
- IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, VDE-AR-N 4105
- Compatibility
- Grid-tied photovoltaic systems
- Communication
- RS485, RS232
- Display
- LCD display
- Monitoring
- GPRS / WiFi / Bluetooth / 4G / LAN (optional)
- Grid Tie
- Yes, with anti-islanding protection
- Installation Type
- Wall-mounted
- Mounting Options
- Wall bracket included
The Deye SUN-25K-G05 is a high-performance three-phase on-grid solar inverter designed for commercial and large residential photovoltaic systems. It converts DC electricity generated by solar panels into stable AC power for grid-connected installations, ensuring efficient energy production and reliable long-term operation.
With advanced MPPT technology, high PV input voltage capability, and excellent conversion efficiency, this inverter is optimized for modern photovoltaic systems where performance, safety, and stability are essential.
Core Electrical Characteristics
- Nominal AC output power of 25 kW for three-phase grid-connected systems
- Three-phase grid connection designed for stable and reliable power delivery
- High conversion efficiency of up to 98.5% for maximum solar energy yield
- Low total harmonic distortion (THD) for compliant and stable grid interaction
- Wide output voltage and frequency compatibility with international grid standards
PV Input and MPPT Performance
- Dual MPPT trackers allowing independent optimization of two PV strings
- Wide MPPT voltage range enabling flexible photovoltaic array design
- Maximum PV input voltage up to 1100 V DC for long string configurations
- High PV input capability suitable for modern high-power solar modules
- Advanced MPPT tracking algorithms for improved performance under varying sunlight conditions
Grid Integration and System Operation
- Designed for grid-tied photovoltaic power systems
- Stable power conversion for continuous solar energy export to the grid
- Support for export limitation and zero-export configurations when required
- Reliable synchronization with the utility grid for stable operation
- Suitable for commercial rooftops and distributed solar installations
Monitoring, Communication, and Control
- Integrated intelligent monitoring platform for system performance tracking
- Optional remote monitoring via WiFi, LAN, GPRS, Bluetooth, or 4G modules
- Communication interfaces supporting RS485 and RS232 protocols
- Real-time monitoring of PV production and inverter operating status
- Remote system configuration and maintenance support
Mechanical Design and Installation
- Compact wall-mounted inverter design for efficient installation
- Robust enclosure suitable for indoor and outdoor environments
- Integrated protection systems for installer and equipment safety
- Clearly labeled connections for fast and reliable installation
- Designed for professional solar installers and EPC projects
Safety, Compliance, and Reliability
- Comprehensive protection including over-voltage, over-current, and short-circuit protection
- Integrated DC reverse polarity and insulation monitoring protection
- Anti-islanding protection for safe grid operation
- High reliability components designed for long service life
- Compliant with international grid and electrical safety standards
Typical Applications
- Commercial solar PV installations
- Large residential photovoltaic systems
- Industrial self-consumption solar projects
- Distributed rooftop solar power systems
- Grid-connected photovoltaic energy systems
