Huawei
Huawei | High Current Inverter | SUN2000-15KTL-M5
Product Code: HW-15KTL-M5
€499.00
+ VAT based on country
High-efficiency 15 kW three-phase on-grid inverter from Huawei’s SUN2000 M5 series, built for residential and commercial PV systems. Dual MPPT, 98.4 % efficiency, and IP65 protection for superior reliability and smart performance.
Key Features
- Rated Output Power: 15 kW
- Max PV Input Power: 22.5 kWp
- Max Efficiency: 98.4 %
- Dual MPPT inputs (independent trackers)
- IP65 protection, DC & AC SPD Type II
- Communication: RS485 / Smart Dongle (optional Wi-Fi or 4G)
- Warranty: 8 years (extendable to 10 years)
Technical Specifications
General
- Brand
- Huawei
- Model
- Huawei | High Current Inverter | SUN2000-15KTL-M5
- SKU
- HW-15KTL-M5
- Power Output
- 15,000 W
- Voltage
- 600 V DC (Nominal)
- Efficiency
- 98.4 % (European Efficiency: 98.0 %)
- Dimensions
- 590 × 355 × 560 mm
- Weight
- 30 kg
- Warranty
- 8 years
Technical
- Input Voltage
- 200 V – 1000 V DC
- Frequency
- 50 / 60 Hz
- Max PV Power
- 22,500 Wp
- Max PV Voltage
- 1100 V DC
- Max PV Current
- 30 A per MPPT
- Nominal Power
- 15,000 W
- Peak Power
- 22,500 Wp
- Transfer Time
- < 20 ms
- THD
- < 3 %
- Power Factor
- 0.8 leading to 0.8 lagging
- Operating Temperature
- –25 °C to +60 °C
- Protection Rating
- IP65
- Cooling
- Natural convection
- Noise Level
- < 29 dB
- Certifications
- CE, EN 50549-1, IEC 62109-1 / 2, VDE-AR-N 4105
- Compatibility
- Huawei Smart Dongle (Wi-Fi / 4G), Smart Logger, FusionSolar App
- Communication
- RS485, Wi-Fi / 4G (via Dongle)
- Monitoring
- FusionSolar Cloud / App based remote monitoring
- Grid Tie
- Yes, with anti-islanding protection
- Installation Type
- Wall-mounted, outdoor and indoor use
- Mounting Options
- Wall bracket included
The Huawei SUN2000-15KTL-M5 is a high-performance three-phase on-grid inverter designed for residential, commercial, and industrial solar PV applications. As part of Huawei’s renowned SUN2000 M5 series, it delivers exceptional energy efficiency up to 98.4 % and robust protection features for long-term durability.
Equipped with dual MPPT inputs, it ensures optimal power generation even under partial shading or variable sunlight. The inverter features IP65-rated protection, Type II SPD on both AC and DC sides, and natural convection cooling, providing stable operation in demanding environments.
With its compact design and easy installation, the SUN2000-15KTL-M5 integrates seamlessly into modern solar systems. It also supports smart monitoring via FusionSolar and RS485 communication, enabling real-time performance tracking and remote updates.
Key Advantages:
- Rated Output Power: 15 kW
- Max PV Input Power: 22.5 kWp
- Max Efficiency: 98.4 %
- Dual MPPT inputs (independent trackers)
- IP65 protection, DC & AC SPD Type II
- Communication: RS485 / Smart Dongle (optional Wi-Fi or 4G)
- Warranty: 8 years (extendable to 10 years)
Built for maximum reliability, energy conversion efficiency, and intelligent management — the Huawei SUN2000-15KTL-M5 sets the benchmark for the new generation of solar inverters.
