HUAWEI - LUNA2000-4.5MWH-2H1

The Huawei LUNA2000-4.5MWH-2H1 is a high-performance, modular energy storage solution designed for large-scale commercial and industrial applications. Housed in a 20-foot high-cube container, it offers a nominal energy capacity of 4,472 kWh and a nominal power output of 2,236 kW, making it ideal for peak shaving, load shifting, and grid stabilization.

Equipped with an advanced liquid cooling system, the LUNA2000-4.5MWH-2H1 ensures optimal operating temperatures, enhancing battery life and system efficiency. Its high round-trip efficiency of up to 93.05% and support for a ≤ 0.5 C charge/discharge rate contribute to reduced energy losses and improved performance.

Safety is paramount, with integrated fire suppression systems (water sprinkler and optional Novec 1230), IP55 protection rating, and corrosion protection class C5-Medium, ensuring reliable operation in various environmental conditions.

The system features seamless integration capabilities via Modbus TCP communication protocol and supports flexible connectivity through Ethernet/SFP interfaces. Its modular design allows for scalability, accommodating future energy demands with ease.

Ideal for utility-scale projects, the Huawei LUNA2000-4.5MWH-2H1 provides a robust and efficient energy storage solution, aligning with sustainable energy goals and enhancing grid resilience.

Specifications:

Model: LUNA2000-4.5MWH-2H1

Type: Modular Smart String Energy Storage System

Nominal Energy Capacity: 4,472 kWh

Nominal Power Output: 2,236 kW

Nominal DC Voltage: 1,331.2 V

Maximum DC Voltage: 1,500 V

Charge/Discharge Rate: ≤ 0.5 C

Round-Trip Efficiency (RTE): Up to 93.05%

Cooling Method: Liquid Cooling

Fire Suppression System: Water Sprinkler, Novec 1230 (Optional)

Protection Rating: IP55

Corrosion Protection: C5-Medium

Communication Interface: Ethernet / SFP

Communication Protocol: Modbus TCP

Operating Temperature Range: –30°C to +55°C

Storage Temperature Range: –40°C to +60°C

Relative Humidity: 0% to 100% (Non-condensing)

Maximum Operating Altitude: 4,700 m

Dimensions (W × H × D): 6,058 mm × 2,896 mm × 2,438 mm

Weight: ≤ 41,000 kg

Battery Pack:

Cell Material: Lithium Iron Phosphate (LFP)

Number of Cells: 104

Nominal Capacity per Cell: 280 Ah

Protection Degree: IP65

Weight per Pack: 670 ± 10 kg

Dimensions per Pack (W × H × D): 785 mm × 249 mm × 2,182 mm

Compatible Inverters: Huawei LUNA2000-213KTL-H0
